Features:
1. Three
independent routing units for automatic routing and drilling of water slots and
ventilation hole in PVC profile.
2. Adopt
advancing Germany technique.
3. Compact
built units’ router units with automatic feed for touting depth and slot
length.
4. Three
motors can be adjustable easily for milling different angle position.
5. Router
can be controlled individually to be flexible for various productions.
6. The
work piece is clamped by two vertical clamping cylinders.
7. Automatic
Pneumatic feeding unit, feeding speed adjustable.
8. Easy
simple measuring assist bar.
9. Sliding
and turret clamp buffers allow quick adjustment.
10. Auto
moving working table ensure nice milling
11. Easy
adjustment to realize symmetrical milling.
Parameter:
Air Pressure
|
0.5~0.8(MPa)
|
Air Consumption
|
30(L/min)
|
Input Voltage
|
220V 50Hz
|
Main-shaft Revolution
|
25000(r/min)
|
Input Power
|
1.14kW
|
Cutter Diameter
|
φ5 φ6 (mm)
|
Slot Depth
|
30(mm)(Max)
|
Slot Length
|
30~60(mm)
|
Overall Dimension
|
110×900×1900(mm)
|
Weight
|
300(kg)
|
Main
accessory:
Solenoid Valve
|
SMC
|
Cylinder
|
JPC(FESTO Joint
Venture Brand)
|
Motor
|
Anhui Sanyang
|
Approach
Switcher
|
Japan Omron
|
Electrical
Button and
|
Schneider
|
AC Contactor
|
Schneider
|
Standard accessory:
Drill bit
|
3pcs
|
Air Gun
|
1pc
|
Complete
tooling
|
1set
|
Certificate
|
1pc
|
