Cutting Saw OSA-500*4200

Features:

1. For cutting Aluminum profile.

2. The feeding system adopts imported linear guide pair, with high accuracy and stability.

3. Auto 45°，67.5and 90°cutting change

4. Imported linear guiding pair ensured steady processing accuracy.

5. Saw blade rotates smoothly due to high accuracy spindle.

6. Hydraulic feeding systems ensure precise and stable feeding.

7. Middle auto-induction profile supporter and following profile supporter make the loading and clamping

convenient.

8. Carbide saw blade is of accurate processing and high efficiency.

9. Two heads can work together or single, when together work, one time can cut off the required length

and angle.

Parameter:

Power supply	3N~50Hz 380/220V or As Customer Specification	Saw-head motor	2×2.2KW 2800r/min
Operation air pressure	0.5～0.8MPa	Air consumption	60L/min
Cutting length	Max 4200mm Min 385mm	Cutting width	Max 135mm
Cutting height	900 : max 300mm 450 : max 200mm	Cutting angle	90°、45°、67.5°(for spare )
Cutting speed	stepless speed regulation 0-3m/min	Blade specification	ø500×ø30×4.4×Z120
Repeat locating length	≤0.2mm	Cutting angle allowance	±5’
Cutting profile surface plane	≤0.1m	Cutting profile surface roughness	Ra12.5μm
Contour dimension	5530×1750×1950 mm	Weight	1800kg

Main accessory:

Saw blade	Wagen	Solenoid valve	Germany FESTO
Cylinder	JPC(FESTO Joint Venture Brand)	Motor	Anhui Sanyang
Air Filter Device	STNC	Electrical Button and Switcher	Schneider
AC Contactor and Circuit Breaker	Schneider	Linear Bearing System	HIWIN

Standard accessory:
